fuzzy_dl_owl2.fuzzydl.milp.show_variables_helper

A configuration manager controls the visibility and display settings of variables, concepts, individuals, and role fillers within a fuzzy description logic system.

Description

It distinguishes between global visibility, which applies to all entities, and specific visibility restricted to particular individuals, thereby allowing for granular control over output data. The logic integrates fuzzy semantics by associating linguistic labels with concrete feature fillers and mapping internal variable objects to human-readable string names. Furthermore, the design supports deep cloning of the entire configuration state, enabling the preservation or branching of display settings during complex reasoning or solving processes.

Classes

ShowVariablesHelper

This class serves as a configuration manager for determining which elements of a fuzzy description logic ontology should be displayed. It enables the selective tracking of atomic concepts, individuals, abstract roles, and concrete features, distinguishing between global visibility—applying to all entities—and specific visibility restricted to particular individuals. Additionally, it manages the mapping of internal variable objects to display names and handles the association of fuzzy linguistic labels with concrete feature fillers. Users can interact with this class to populate these sets, query visibility status, and clone the entire configuration state to preserve or branch the current display settings.

Module Contents

UML Class Diagram for ShowVariablesHelper

class ShowVariablesHelper

This class serves as a configuration manager for determining which elements of a fuzzy description logic ontology should be displayed. It enables the selective tracking of atomic concepts, individuals, abstract roles, and concrete features, distinguishing between global visibility—applying to all entities—and specific visibility restricted to particular individuals. Additionally, it manages the mapping of internal variable objects to display names and handles the association of fuzzy linguistic labels with concrete feature fillers. Users can interact with this class to populate these sets, query visibility status, and clone the entire configuration state to preserve or branch the current display settings.

Parameters:

• abstract_fillers (dict[str, set[str]]) – Maps abstract role names to sets of specific individuals for which the role’s fillers should be displayed.

• concepts (set[str]) – A set of atomic concept names for which the membership degree of every individual should be displayed.

• concrete_fillers (dict[str, set[str]]) – A dictionary mapping the name of a concrete feature to a set of individuals for which the filler of that feature should be displayed.

• global_abstract_fillers (set[str]) – Names of abstract roles for which to show fillers for every individual.

• global_concrete_fillers (set[str]) – A set of concrete feature names for which the fillers are to be shown for every individual.

• individuals (set[str]) – Names of individuals for which the membership degree to every atomic concept should be displayed.

• labels_for_fillers (dict[str, list[FuzzyConcreteConcept]]) – Maps a variable name to a list of fuzzy concrete concepts representing the linguistic labels to be displayed for that variable.

• variables (dict[Variable, str]) – Stores the variables to be displayed, mapping each variable object to its corresponding display name string.

__add_abstract_filler_to_show_1(role_name: str) → None

Registers the specified abstract role name within the global collection of abstract fillers intended for display. As a side effect, it removes the role from the local abstract_fillers mapping if it is currently present, effectively promoting the role to a global scope and ensuring it is handled by the global display logic rather than being treated as a specific, local filler.

Parameters:

role_name (str) – Name of the abstract role to be added to the global abstract fillers set.

__add_abstract_filler_to_show_2(role_name: str, ind_name: str) → None

Registers an individual as a filler for a specific abstract role within the helper’s internal state, provided the role is not globally defined. If the role name is not found in the global_abstract_fillers collection, the method adds the individual name to the set of fillers associated with that role in the abstract_fillers dictionary. This ensures that only non-global abstract roles are tracked for the specific individual, modifying the instance state directly without returning a value.

Parameters:

• role_name (str) – The name of the abstract role to which the individual is being added as a filler.

• ind_name (str) – The name of the individual to be added as a filler for the abstract role.

__add_concrete_filler_to_show_1(f_name: str) → None

Adds the specified concrete feature name to the set of global concrete fillers, marking it for display in a global context. If the feature is currently present in the local concrete fillers collection, it is removed to ensure it is not tracked redundantly. This method modifies the internal state of the helper by promoting the feature from a local to a global scope.

Parameters:

f_name (str) – The name of the concrete feature to be displayed.

__add_concrete_filler_to_show_2(f_name: str, ind_name: str) → None

Registers the specified individual as a concrete filler for the given feature within the helper’s internal tracking structure. This operation is conditional; if the feature is already present in the global concrete fillers collection, the method returns immediately without making changes. Otherwise, the individual is added to the set of fillers associated with the feature name in the instance’s concrete fillers dictionary.

Parameters:

• f_name (str) – The name of the concrete feature to associate with the individual, provided it is not a global feature.

• ind_name (str) – The name of the individual to be added to the set of fillers associated with the concrete feature.

__add_concrete_filler_to_show_3(

f_name: str,

ind_name: str,

ar: list[fuzzy_dl_owl2.fuzzydl.concept.concrete.fuzzy_concrete_concept.FuzzyConcreteConcept],

) → None

Registers a concrete feature of an individual for display and associates a list of fuzzy concrete concepts (linguistic labels) with it. The method first ensures the feature-individual pair is tracked by calling add_concrete_filler_to_show. It then retrieves any existing labels associated with the pair; if labels already exist, the provided list of concepts is appended to them, otherwise, the list is stored directly. This process updates the internal labels_for_fillers dictionary to aggregate membership degrees for visualization.

Parameters:

• f_name (str) – The name of the concrete feature for which membership degrees are being displayed.

• ind_name (str) – The name of the individual entity that possesses the concrete feature, used to uniquely identify the specific feature instance.

• ar (list[FuzzyConcreteConcept]) – List of fuzzy concrete concepts representing linguistic labels to be displayed for the feature filler.

add_abstract_filler_to_show(role_name: str) → None

add_abstract_filler_to_show(role_name: str, ind_name: str) → None

Configures the display settings to show the membership degrees of atomic concepts associated with the fillers of a specified abstract role. This method serves as a dispatcher that validates input types and argument counts before delegating the logic to internal helper methods. It accepts either one or two string arguments, corresponding to different modes of specifying the abstract role and its fillers, and will raise an assertion error if the provided arguments are not strings or if the number of arguments is incorrect.

Parameters:

args (Any) – One or two string arguments identifying the abstract role and optionally a specific filler or concept.

add_concept_to_show(conc_name: str) → None

Registers an atomic concept name to the internal collection of variables to be displayed, ensuring that the membership degree for every instance of this concept is tracked. This method modifies the state of the helper by adding the specified string to the set of active concepts. It is idempotent, meaning that adding the same concept name multiple times will not alter the state beyond the first addition.

Parameters:

conc_name (str) – Name of the atomic concept to include in the display.

add_concrete_filler_to_show(f_name: str) → None

add_concrete_filler_to_show(f_name: str, ind_name: str) → None

add_concrete_filler_to_show(

f_name: str,

ind_name: str,

ar: list[fuzzy_dl_owl2.fuzzydl.concept.concrete.fuzzy_concrete_concept.FuzzyConcreteConcept],

) → None

Registers a concrete feature’s filler value for display, acting as a dispatcher that delegates to internal helper methods based on the number of arguments provided. The first argument must always be a string identifying the feature name. If only one argument is supplied, the method processes the feature using minimal context; if two arguments are supplied, the second must be a string representing a specific value or attribute; and if three arguments are supplied, the second must be a string and the third must be a list of FuzzyConcreteConcept objects to define the filler using fuzzy logic. The method raises an AssertionError if the argument count is not between one and three or if the types of the arguments do not conform to these specific patterns. This function modifies the internal state of the ShowVariablesHelper to include the specified filler in the display configuration but returns no value.

Parameters:

args (Any) – Variable arguments defining the concrete feature, comprising a feature name (str), optionally a filler (str), and optionally a list of FuzzyConcreteConcepts.

add_individual_to_show(ind_name: str) → None

Registers the specified individual name to be tracked or displayed by adding it to the internal collection of individuals. This method modifies the state of the helper object by inserting the name into the set. If the individual name is already present in the collection, the operation has no effect.

Parameters:

ind_name (str) – The name of the individual to be added to the display set.

add_variable(var: fuzzy_dl_owl2.fuzzydl.milp.variable.Variable, name_to_show: str) → None

Registers a specific Variable instance for display, associating it with a custom string label to be used when rendering or presenting the variable. This method updates the internal state of the helper by storing the mapping between the variable object and its designated display name. If the variable is already present in the collection, the existing display name will be overwritten with the new value, ensuring that the most recent label is retained.

Parameters:

• var (Variable) – The variable object to be added for display.

• name_to_show (str) – The display name to use for the variable.

clone() → Self

Creates and returns a deep copy of the current ShowVariablesHelper instance. This method ensures that the new instance is independent of the original by performing a deep copy on complex attributes such as abstract_fillers, concepts, concrete_fillers, global_abstract_fillers, global_concrete_fillers, and individuals. For labels_for_fillers and variables, it constructs new dictionary and list containers to isolate the structure, though the contained elements are copied by reference. The original object remains unmodified during this process.

Returns:

A new instance that is a deep copy of the current object.

Return type:

Self

get_labels(var_name: str) → list[fuzzy_dl_owl2.fuzzydl.concept.concrete.fuzzy_concrete_concept.FuzzyConcreteConcept]

Retrieves the list of fuzzy concrete concepts designated for display for a specific variable. It queries the internal mapping of variable names to their associated labels. If the provided variable name is not found in the mapping, the method returns an empty list rather than raising an exception.

Parameters:

var_name (str) – Identifier of the variable whose associated fuzzy concrete concepts are to be retrieved.

Returns:

A list of fuzzy concrete concepts marked to be shown for the specified variable. Returns an empty list if the variable has no associated labels.

Return type:

list[FuzzyConcreteConcept]

get_name(var: fuzzy_dl_owl2.fuzzydl.milp.variable.Variable) → str

Retrieves the string name associated with a given Variable instance by querying the internal mapping of variables. This method serves as a read-only accessor to resolve variable objects to their string identifiers. If the specified variable is not present in the internal collection, the method returns None.

Parameters:

var (Variable) – The variable instance for which to retrieve the name.

Returns:

The string name associated with the specified variable.

Return type:

str

get_variables() → list[fuzzy_dl_owl2.fuzzydl.milp.variable.Variable]

Returns a list of variables currently managed by the helper for display purposes. This method retrieves the keys from the internal variables mapping and returns them as a new list, ensuring that modifications to the returned collection do not affect the helper’s internal state. If no variables are stored, an empty list is returned.

Returns:

A list of the variable keys intended for display.

Return type:

list[Variable]

show_abstract_role_fillers(role_name: str, ind_name: str) → bool

Determines whether the fillers of a specified abstract role should be displayed for a given individual. The method first checks if the role is globally enabled for display; if so, it returns true regardless of the individual. If the role is not global, it verifies whether the specific individual is explicitly listed in the set of fillers for that role, returning true only if the individual is present. This method does not modify any internal state.

Parameters:

• role_name (str) – Name of the abstract role to check for filler visibility.

• ind_name (str) – Name of the individual to check if they are marked to display all fillers of the abstract role.

Returns:

True if the abstract role is globally enabled or if the individual is explicitly marked to show fillers for that role; otherwise, False.

Return type:

bool

show_concepts(concept_name: str) → bool

Checks whether a given atomic concept is included in the internal registry of concepts designated for visualization or detailed output. This method verifies the presence of the specified concept name within the helper’s stored collection, effectively determining if the membership degrees of individuals for this concept should be displayed. The check is case-sensitive and relies on exact string matching. Since this is a query operation, it does not modify the internal state of the object or the provided arguments.

Parameters:

concept_name (str) – The name of the atomic concept to check for display status.

Returns:

True if the atomic concept is marked to show the membership degree of every individual; otherwise, False.

Return type:

bool

show_concrete_fillers(f_name: str, ind_name: str) → bool

Determines whether the fillers of a specific concrete feature should be displayed for a given individual. If the feature is currently marked as global, the method returns True, indicating that fillers are shown for all individuals. Otherwise, it checks the specific configuration for that feature to see if the individual is explicitly listed; the method returns False if the feature is not global and the individual is not found in the specific configuration or if the configuration for the feature is missing. This method performs a read-only check and does not modify the state of the helper.

Parameters:

• f_name (str) – The name of the concrete feature for which filler visibility is being determined.

• ind_name (str) – Name of the individual to check for the display setting.

Returns:

True if the fillers for the specified concrete feature should be displayed for the given individual, based on global feature settings or explicit individual markings.

Return type:

bool

show_individuals(ind_name: str) → bool

Evaluates the visibility status of a specific individual by checking if its name exists within the internal registry of active individuals. This method acts as a filter, returning True if the individual is present in the registry and should be shown, and False otherwise. It performs a read-only lookup and does not modify the internal state of the helper object.

Parameters:

ind_name (str)

Returns:

True if the specified individual is marked to be shown, False otherwise.

Return type:

bool

show_variable(var: fuzzy_dl_owl2.fuzzydl.milp.variable.Variable) → bool

Determines whether a specific variable is present within the internal collection managed by the helper. It performs a membership check against the stored variables and returns a boolean value indicating if the variable is currently tracked. This method is a read-only operation and does not modify the state of the helper or the variable itself.

Parameters:

var (Variable) – The variable to check for existence.

Returns:

True if the variable exists, False otherwise.

Return type:

bool

abstract_fillers: dict[str, set[str]]

concepts: set[str]

concrete_fillers: dict[str, set[str]]

global_abstract_fillers: set[str]

global_concrete_fillers: set[str]

individuals: set[str]

labels_for_fillers: dict[str, list[fuzzy_dl_owl2.fuzzydl.concept.concrete.fuzzy_concrete_concept.FuzzyConcreteConcept]]

variables: dict[fuzzy_dl_owl2.fuzzydl.milp.variable.Variable, str]
