fuzzy_dl_owl2.fuzzydl.concept.concrete.linear_concrete_concept
A concrete implementation of a fuzzy concept that utilizes a piecewise linear membership function defined over a normalized domain.
Description
This software component models a specific type of fuzzy concept characterized by a piecewise linear membership function operating on a normalized domain ranging from zero to one. The mathematical behavior is governed by a “knee” point defined by parameters a and b, which creates a linear ramp from the origin to the knee and a second ramp from the knee to full membership, effectively ignoring the interval bounds k1 and k2 during the actual calculation of the membership degree. Validation logic ensures that the definition interval and the knee point adhere to specific constraints, such as requiring the lower bound to be less than or equal to the knee position and the membership degree at the knee to not exceed one. Beyond calculating membership degrees through linear interpolation, the implementation supports standard fuzzy logic operations like negation, conjunction, and disjunction by delegating these tasks to a central operator handler. It also provides functionality for cloning instances and generating a canonical string representation based on its defining parameters.
Classes
This class models a fuzzy concept characterized by a piecewise linear membership function operating on a normalized domain from 0 to 1. The function is defined by a specific "knee" point determined by parameters a and b, creating a linear ramp from (0, 0) to (a, b) and a second linear ramp from (a, b) to (1, 1). While the constructor accepts parameters k1 and k2 to denote the definition interval, the membership calculation logic strictly relies on the normalized input value and the a and b parameters. To use this class, instantiate it with a name and the required float parameters, ensuring that k1 is less than or equal to a and b does not exceed 1.0 to avoid validation errors. Once instantiated, the membership degree of a specific value can be retrieved using the get_membership_degree method, and the object supports standard fuzzy logic operations such as negation, conjunction, and disjunction. |
Module Contents
UML Class Diagram for LinearConcreteConcept
- class LinearConcreteConcept(name: str, k1: float, k2: float, a: float, b: float)
Bases:
fuzzy_dl_owl2.fuzzydl.concept.concrete.fuzzy_concrete_concept.FuzzyConcreteConcept
This class models a fuzzy concept characterized by a piecewise linear membership function operating on a normalized domain from 0 to 1. The function is defined by a specific “knee” point determined by parameters a and b, creating a linear ramp from (0, 0) to (a, b) and a second linear ramp from (a, b) to (1, 1). While the constructor accepts parameters k1 and k2 to denote the definition interval, the membership calculation logic strictly relies on the normalized input value and the a and b parameters. To use this class, instantiate it with a name and the required float parameters, ensuring that k1 is less than or equal to a and b does not exceed 1.0 to avoid validation errors. Once instantiated, the membership degree of a specific value can be retrieved using the get_membership_degree method, and the object supports standard fuzzy logic operations such as negation, conjunction, and disjunction.
- Parameters:
k1 (float) – Lower bound of the interval for which the concept is defined.
k2 (float) – The upper bound of the interval for which the concept is defined.
_a (float) – The lower bound of the interval for which the concept is satisfied, acting as a threshold in the piecewise linear membership function.
_b (float) – The membership degree at the threshold a, defining the slope of the linear membership function. Must be less than or equal to 1.0.
- __and__(value: Self) Self
Computes the logical conjunction or intersection of the current concept with another instance of the same type. This method enables the use of the bitwise AND operator (&) to combine concepts, delegating the specific logic to the OperatorConcept.and_ method. The operation returns a new instance representing the result, leaving the original operands unchanged.
- Parameters:
value (Self) – The right-hand operand for the AND operation, which must be an instance of the same type.
- Returns:
The result of the AND operation between this instance and the provided value.
- Return type:
Self
- __hash__() int
Return a hash value for this object, computed from its string representation. This approach ensures that the hash value reflects the structural identity of the object without relying on cached values or additional methods. The hash is derived from the output of the __str__ method, which provides a consistent and unique representation of the concept’s structure. This implementation does not utilize any internal caching mechanism and directly computes the hash each time it is called.
- Returns:
An integer hash value representing the structural identity of this object.
- Return type:
int
- __neg__() fuzzy_dl_owl2.fuzzydl.concept.concrete.fuzzy_concrete_concept.FuzzyConcreteConcept
Implements the unary negation operator, allowing the concept to be inverted using the - prefix. This method delegates the logic to OperatorConcept.not_ to compute the logical complement of the current instance. The operation returns a new FuzzyConcreteConcept representing the negation, rather than modifying the original object.
- Returns:
A new FuzzyConcreteConcept representing the logical negation of the current concept.
- Return type:
- __or__(value: Self) Self
Performs a logical OR operation between the current concept and another concept of the same type. This method enables the use of the pipe operator (|) to combine concepts, delegating the underlying logic to the OperatorConcept.or_ method. It returns a new instance representing the result of the operation, leaving the original operands unchanged.
- Parameters:
value (Self) – The right-hand operand to combine with the current instance using the OR operation.
- Returns:
Returns a new instance representing the logical OR of this object and the provided value.
- Return type:
Self
- clone() Self
Creates and returns a new instance of the class that is a distinct copy of the current object. This method initializes the new instance using the values of the name, k1, k2, a, and b attributes from the original object. The operation does not modify the state of the existing instance, ensuring that the original and the clone are independent objects with identical initial data.
- Returns:
A new instance of the class initialized with the same attribute values as the current object.
- Return type:
Self
- compute_name() str
Constructs a descriptive name for the linear concept instance by interpolating its key parameters into a standardized string format. The method retrieves the values of k1, k2, a, and b from the instance state and returns them formatted as “linear(k1, k2, a, b)”. This function is purely deterministic and has no side effects, relying solely on the current state of the object’s attributes.
- Returns:
A string representation of the linear function formatted with the current parameters.
- Return type:
str
- get_membership_degree(value: float) float
Calculates the degree of membership for a given input value based on a piecewise linear function defined by the concept’s parameters. The input is treated as a normalized value, where any input less than or equal to zero results in a membership of 0.0, and any input greater than or equal to one results in a membership of 1.0. Between zero and the internal threshold self.a, the membership increases linearly from 0.0 to self.b. For values between self.a and 1.0, the membership increases linearly from self.b to 1.0. This method does not modify the state of the object.
- Parameters:
value (float) – The input value to evaluate against the membership function. Values less than or equal to 0 return 0, and values greater than or equal to 1 return 1.
- Returns:
The calculated degree of membership for the input value, bounded between 0.0 and 1.0.
- Return type:
float
- _a: float
- _b: float
- property a: float
Returns the x-coordinate of the knee of this piecewise-linear membership function, i.e. the threshold on the normalized domain at which the slope of the ramp changes. The value is held internally as a float and is read without modifying the instance.
- Returns:
The knee position
aof the linear function.- Return type:
float
- property b: float
Returns the membership degree reached at the knee
aof this piecewise-linear function, i.e. the y-coordinate of the breakpoint that fixes the slope of the two linear segments. The value is held internally as a float and is read without modifying the instance.- Returns:
The membership degree
bat the knee.- Return type:
float
- k1: float
- k2: float
