fuzzy_dl_owl2.fuzzydl.concept.concrete.right_concrete_concept
A Python implementation of a fuzzy logic concept that utilizes a right-shoulder membership function to model values where truth increases linearly over a specific interval.
Description
The software models a specific type of fuzzy set where the degree of membership transitions from zero to one as an input value increases, effectively representing concepts that become truer as a variable grows larger. The implementation relies on geometric parameters to define the domain and the transition interval, ensuring that the domain boundaries fully encapsulate the specific range where the membership ramps up. During initialization, strict validation logic enforces ordering constraints between these boundaries to guarantee structural integrity and mathematical consistency. Beyond calculating membership degrees through linear interpolation, the implementation supports standard fuzzy logic operations such as negation, conjunction, and disjunction by delegating these tasks to a central operator handler. Functionality for cloning instances and generating hash values based on the defining parameters is also included to support object identity and comparison within the broader system.
Classes
This class models a specific type of fuzzy logic concept characterized by a "right shoulder" membership function, where the degree of truth increases linearly from zero to one over a specified interval. It is typically used to represent concepts that become increasingly true as a variable grows larger, such as "high temperature" or "large size." To use this class, instantiate it with a name, the domain boundaries (k1, k2) defining the valid range of the variable, and the transition boundaries (a, b) defining the interval over which the membership ramps up. The class ensures structural integrity by validating that the domain fully encompasses the transition interval and that the transition boundaries are ordered correctly. Once instantiated, the membership degree for any value can be calculated using the get_membership_degree method, and the concept supports standard fuzzy logic operations like negation, conjunction, and disjunction. |
Module Contents
UML Class Diagram for RightConcreteConcept
- class RightConcreteConcept(name: str, k1: float, k2: float, a: float, b: float)
Bases:
fuzzy_dl_owl2.fuzzydl.concept.concrete.fuzzy_concrete_concept.FuzzyConcreteConcept
This class models a specific type of fuzzy logic concept characterized by a “right shoulder” membership function, where the degree of truth increases linearly from zero to one over a specified interval. It is typically used to represent concepts that become increasingly true as a variable grows larger, such as “high temperature” or “large size.” To use this class, instantiate it with a name, the domain boundaries (k1, k2) defining the valid range of the variable, and the transition boundaries (a, b) defining the interval over which the membership ramps up. The class ensures structural integrity by validating that the domain fully encompasses the transition interval and that the transition boundaries are ordered correctly. Once instantiated, the membership degree for any value can be calculated using the get_membership_degree method, and the concept supports standard fuzzy logic operations like negation, conjunction, and disjunction.
- Parameters:
k1 (float) – The lower bound of the domain interval over which the concept is defined.
k2 (float) – The upper bound of the interval [k1, k2] defining the domain of the concept.
_a (float) – The lower bound of the interval for which the concept is satisfied, representing the threshold where the membership degree begins to increase from zero.
_b (float) – The upper bound of the satisfaction interval, representing the threshold where the membership degree becomes 1.
- __and__(value: Self) Self
Performs a logical or bitwise conjunction between the current instance and another instance of the same type, typically invoked via the & operator. This method delegates the core logic to the and_ static method of the OperatorConcept class, ensuring that the operation is handled consistently within the broader module architecture. It returns a new instance of the class representing the result of the conjunction, leaving the original operands unchanged unless the underlying OperatorConcept implementation specifies otherwise.
- Parameters:
value (Self) – The operand to perform the AND operation with.
- Returns:
A new instance representing the logical conjunction of this object and the provided value.
- Return type:
Self
- __hash__() int
Return a hash value for this object, computed from its string representation. This approach ensures that the hash value reflects the structural identity of the object without relying on cached values or additional methods. The hash is derived from the output of the __str__ method, which provides a consistent and unique representation of the concept’s structure. This implementation does not utilize any internal caching mechanism and directly computes the hash each time it is called.
- Returns:
An integer hash value representing the structural identity of this object.
- Return type:
int
- __neg__() fuzzy_dl_owl2.fuzzydl.concept.concrete.fuzzy_concrete_concept.FuzzyConcreteConcept
Implements the unary negation operator, allowing the concept to be inverted using the minus sign. This method returns a new FuzzyConcreteConcept representing the logical negation of the current instance, effectively computing the complement of the concept. The operation is performed by delegating to OperatorConcept.not_ and does not modify the original object in place.
- Returns:
A FuzzyConcreteConcept representing the logical negation of the current concept.
- Return type:
- __or__(value: Self) Self
Implements the bitwise OR operation using the | operator, allowing the instance to be combined with another value of the same type. The method delegates the specific logic of the operation to OperatorConcept.or_, passing both the current instance and the provided value as arguments. It returns the resulting instance, which maintains the type of the operands, though any side effects depend on the implementation of the delegated or_ method.
- Parameters:
value (Self) – The right-hand operand to combine with the current instance using the OR operation.
- Returns:
The result of the OR operation between this instance and the provided value.
- Return type:
Self
- clone() Self
Creates and returns a distinct copy of the current instance by instantiating a new RightConcreteConcept object. The new object is initialized with the exact same values for the name, k1, k2, a, and b attributes as the original. This method ensures that the original object remains unmodified while providing a separate entity with identical state.
- Returns:
A new instance of the class initialized with the same attribute values as the current object.
- Return type:
Self
- compute_name() str
Generates a standardized string representation of the right-shoulder concept instance by interpolating the object’s defining parameters into a specific format. The returned string follows the pattern “right-shoulder(k1, k2, a, b)”, utilizing the values of the corresponding attributes. This operation is read-only and does not alter the state of the object, though it requires that the necessary attributes exist on the instance.
- Returns:
A string representing the name of the right-shoulder function, formatted with the current parameters k1, k2, a, and b.
- Return type:
str
- get_membership_degree(x: float) float
Calculates the membership degree of a given value x within a right-shoulder fuzzy set defined by the parameters a and b. The function returns 0.0 if x is less than or equal to a, and 1.0 if x is greater than or equal to b. For values falling strictly between a and b, the method computes a linear interpolation, returning a value between 0.0 and 1.0 that represents the proportional distance of x from the lower bound a. This calculation is stateless and does not modify the object’s attributes.
- Parameters:
x (float) – The input value to evaluate for membership.
- Returns:
The degree of membership of x in the interval [a, b], ranging from 0.0 to 1.0 based on linear interpolation.
- Return type:
float
- _a: float
- _b: float
- property a: float
Returns the left breakpoint of this right-shoulder membership function, i.e. the point up to which the degree is
0and beyond which it starts increasing linearly toward one. The value is held internally as a float and is read without modifying the instance.- Returns:
The breakpoint
awhere the degree begins to rise from0.- Return type:
float
- property b: float
Returns the right breakpoint of this right-shoulder membership function, i.e. the point at which the degree reaches its maximum value of
1. The value is held internally as a float and is read without modifying the instance.- Returns:
The breakpoint
bwhere the degree reaches1.- Return type:
float
- k1: float
- k2: float
