fuzzy_dl_owl2.fuzzydl.concept.concrete.triangular_concrete_concept
Implements a fuzzy logic concept using a triangular membership function to determine the degree of membership for numeric values within a defined domain.
Description
The software models a specific type of fuzzy set where membership degrees follow a triangular shape, rising linearly to a peak and then falling back to zero. It requires defining a domain interval alongside three specific points that determine the start, peak, and end of the triangle, enforcing strict validation to ensure the geometric constraints are met during instantiation. Central to the implementation is the calculation of membership degrees, which evaluates a given numeric value against the triangle’s vertices to return a value between zero and one based on linear interpolation. To support complex fuzzy logic reasoning, the implementation overloads standard logical operators such as negation, conjunction, and disjunction, delegating these operations to a separate handler while maintaining the ability to clone instances and generate unique hash identifiers based on the defining parameters.
Classes
This class implements a fuzzy logic concept characterized by a triangular membership function, defining how strongly a specific value belongs to the concept. It operates within a defined domain interval [k1, k2] and establishes a core satisfaction interval [a, c], where the membership degree rises linearly from the lower bound a to a peak of 1.0 at b, then decreases linearly to the upper bound c. Users can instantiate this class with specific boundary parameters to model linguistic variables or fuzzy sets, and subsequently evaluate the membership degree of any given numeric value using the get_membership_degree method. The class enforces strict validation to ensure the parameters form a valid triangle and that the definition interval encompasses the satisfaction interval, raising an exception if these constraints are violated. |
Module Contents
UML Class Diagram for TriangularConcreteConcept
- class TriangularConcreteConcept(name: str, k1: float, k2: float, a: float, b: float, c: float)
Bases:
fuzzy_dl_owl2.fuzzydl.concept.concrete.fuzzy_concrete_concept.FuzzyConcreteConcept
This class implements a fuzzy logic concept characterized by a triangular membership function, defining how strongly a specific value belongs to the concept. It operates within a defined domain interval [k1, k2] and establishes a core satisfaction interval [a, c], where the membership degree rises linearly from the lower bound a to a peak of 1.0 at b, then decreases linearly to the upper bound c. Users can instantiate this class with specific boundary parameters to model linguistic variables or fuzzy sets, and subsequently evaluate the membership degree of any given numeric value using the get_membership_degree method. The class enforces strict validation to ensure the parameters form a valid triangle and that the definition interval encompasses the satisfaction interval, raising an exception if these constraints are violated.
- Parameters:
k1 (float) – The lower bound of the domain interval [k1, k2] over which the concept is defined.
k2 (float) – The upper bound of the domain interval [k1, k2] for which the concept is defined.
_a (float) – The lower bound of the support interval for the triangular membership function, representing the point where the membership degree begins to increase from zero.
_b (float) – The peak value of the triangular membership function where the concept is fully satisfied, corresponding to a membership degree of 1.
_c (float) – The upper bound of the interval for which the concept is satisfied, representing the point where the membership degree drops to zero. It must be greater than or equal to the peak value b.
- Raises:
FuzzyOntologyException – Raised if the provided parameters do not satisfy the constraints for a valid triangular function, specifically if the satisfaction interval bounds are not ordered ($a le b le c$) or if the definition interval $[k_1, k_2]$ does not fully encompass the satisfaction interval $[a, c]$ (i.e., $k_1 > a$ or $k_2 < c$).
- __and__(value: Self) Self
Implements the bitwise or logical AND operation for the class, allowing instances to be combined using the & operator. This method accepts another instance of the same type and delegates the calculation to the OperatorConcept.and_ method to determine the result. The operation returns a new instance of the same type, representing the conjunction of the current instance and the provided value.
- Parameters:
value (Self) – The right-hand operand to perform the AND operation with.
- Returns:
The result of the AND operation between this instance and the provided value.
- Return type:
Self
- __hash__() int
Return a hash value for this object, computed from its string representation. This approach ensures that the hash value reflects the structural identity of the object without relying on cached values or additional methods. The hash is derived from the output of the __str__ method, which provides a consistent and unique representation of the concept’s structure. This implementation does not utilize any internal caching mechanism and directly computes the hash each time it is called.
- Returns:
An integer hash value representing the structural identity of this object.
- Return type:
int
- __neg__() fuzzy_dl_owl2.fuzzydl.concept.concrete.fuzzy_concrete_concept.FuzzyConcreteConcept
Implements the unary negation operator to compute the logical complement of the current triangular concept. This method delegates the operation to OperatorConcept.not_, effectively inverting the membership function associated with the instance. It returns a new FuzzyConcreteConcept representing the negated value without modifying the original object.
- Returns:
The logical negation of the concept.
- Return type:
- __or__(value: Self) Self
Implements the bitwise OR operator (|) to perform a logical disjunction between the current instance and another TriangularConcreteConcept. This method accepts a value of the same type and delegates the computation to the or_ method of OperatorConcept. It returns a new instance of TriangularConcreteConcept representing the result of the operation, without modifying the original operands.
- Parameters:
value (Self) – The right-hand operand for the OR operation, which must be an instance of the same class.
- Returns:
The result of the OR operation between this instance and the provided value.
- Return type:
Self
- clone() Self
Creates and returns a distinct copy of the current TriangularConcreteConcept instance. The new object is instantiated with the exact same values for the name, k1, k2, a, b, and c attributes as the original. This operation does not modify the state of the existing object, ensuring that the original and the clone are independent entities.
- Returns:
A new instance of the class initialized with the same attributes as the current object.
- Return type:
Self
- compute_name() str
Generates a standardized string identifier for the triangular concept based on its current configuration. This method formats the instance attributes k1, k2, a, b, and c into a string that mimics a function invocation syntax. The operation is read-only and produces a unique textual representation of the object’s parameters without causing any side effects.
- Returns:
A string representing the name of the triangular distribution, formatted with its parameters.
- Return type:
str
- get_membership_degree(x: float) float
Calculates the membership degree of a specific value x within the triangular fuzzy set represented by this concept. The membership is determined by the relative position of x between the three defining parameters a (start), b (peak), and c (end). If x lies outside the interval $[a, c]$, the method returns 0.0. For values in the rising interval between a and b, the result is a linear interpolation from 0.0 to 1.0, while values in the falling interval between b and c yield a linear interpolation from 1.0 back to 0.0. This method performs a pure calculation without modifying the object’s state.
- Parameters:
x (float) – The input value for which the membership degree is calculated.
- Returns:
The degree of membership of x in the triangular fuzzy set, ranging from 0.0 (no membership) to 1.0 (full membership).
- Return type:
float
- _a: float
- _b: float
- _c: float
- property a: float
Returns the left breakpoint of the triangular membership function, i.e. the start of the support interval where the membership degree begins rising from zero toward the peak. The value is held internally as a float and is read without modifying the instance.
- Returns:
The lower support bound
aof the triangle.- Return type:
float
- property b: float
Returns the peak breakpoint of the triangular membership function, i.e. the single point where the membership degree reaches its maximum value of
1. The value is held internally as a float and is read without modifying the instance.- Returns:
The peak
bof the triangle.- Return type:
float
- property c: float
Returns the right breakpoint of the triangular membership function, i.e. the end of the support interval where the membership degree falls back to zero. The value is held internally as a float and is read without modifying the instance.
- Returns:
The upper support bound
cof the triangle.- Return type:
float
- k1: float
- k2: float
