fuzzy_dl_owl2.fuzzydl.degree.degree_variable
Defines a symbolic representation of a degree of satisfaction using an algebraic variable to enable dynamic constraint generation within a fuzzy logic system.
Description
This component acts as a symbolic wrapper for a degree of satisfaction, allowing the magnitude to be represented by an algebraic variable rather than a fixed numeric constant. By bridging the gap between abstract fuzzy logic concepts and linear algebra, it enables the creation of mathematical expressions and constraints where the satisfaction level is an unknown value to be solved for. The implementation supports various algebraic manipulations, such as addition, subtraction, and scalar multiplication, which are essential for constructing the complex linear equations required by the underlying solver. Furthermore, it distinguishes itself from numeric degrees by explicitly identifying as non-numeric, ensuring that the system treats it as a dynamic entity during constraint generation and type checking.
Classes
This class encapsulates a symbolic representation of a degree of satisfaction, where the magnitude is not a fixed numeric value but is instead defined by a variable. It serves as a bridge between the abstract concept of a "degree" and the algebraic manipulation of variables, allowing the degree to participate in mathematical expressions and constraints. By wrapping a Variable instance, it enables operations such as addition, subtraction, and scalar multiplication within expressions, as well as the creation of inequalities where the variable acts as the right-hand side. Unlike numeric degrees, this entity is identified as non-numeric, making it suitable for contexts where the satisfaction level is dynamic or unknown and must be solved for rather than hardcoded. |
Module Contents
UML Class Diagram for DegreeVariable
- class DegreeVariable(variable: fuzzy_dl_owl2.fuzzydl.milp.variable.Variable)[source]
Bases:
fuzzy_dl_owl2.fuzzydl.degree.degree.Degree
This class encapsulates a symbolic representation of a degree of satisfaction, where the magnitude is not a fixed numeric value but is instead defined by a variable. It serves as a bridge between the abstract concept of a “degree” and the algebraic manipulation of variables, allowing the degree to participate in mathematical expressions and constraints. By wrapping a Variable instance, it enables operations such as addition, subtraction, and scalar multiplication within expressions, as well as the creation of inequalities where the variable acts as the right-hand side. Unlike numeric degrees, this entity is identified as non-numeric, making it suitable for contexts where the satisfaction level is dynamic or unknown and must be solved for rather than hardcoded.
- Parameters:
variable (Variable) – Symbolic variable representing the degree, used to construct algebraic expressions and inequalities.
- __eq__(degree: fuzzy_dl_owl2.fuzzydl.degree.degree.Degree) bool[source]
Determines whether the current DegreeVariable instance is equal to another object. Equality is established only if the provided argument is also an instance of DegreeVariable and the underlying variable, accessed via get_variable(), is identical to that of the current instance. If the argument is of a different type or the underlying variables do not match, the method returns False.
- Parameters:
degree (Degree) – The degree object to compare against for equality.
- Returns:
True if the provided object is a DegreeVariable representing the same underlying variable, otherwise False.
- Return type:
bool
- __str__() str[source]
Returns a human-readable string representation of the DegreeVariable instance, formatted as “Degree(variable)” where “variable” is the value of the instance’s variable attribute. This method is implicitly invoked by the built-in str() function and print operations. It performs no side effects on the object’s state, though it relies on the string conversion of the underlying variable attribute.
- Returns:
Returns a string representation of the object in the format ‘Degree(variable)’.
- Return type:
str
- add_to_expression(expr: fuzzy_dl_owl2.fuzzydl.milp.expression.Expression) fuzzy_dl_owl2.fuzzydl.milp.expression.Expression[source]
Incorporates the variable represented by this DegreeVariable into a given expression by adding it as a term with a coefficient of 1.0. The method returns a new Expression object representing the sum of the input and the variable, ensuring that the original expression is not modified. This function is primarily used for incrementally constructing expressions where the specific degree variable needs to be included, relying on the underlying Expression class to handle the addition logic.
- Parameters:
expr (Expression) – The expression to which the term is added.
- Returns:
The resulting Expression after adding a term with a coefficient of 1.0 and the instance’s variable to the input expression.
- Return type:
- clone() Self[source]
Creates and returns a new instance of DegreeVariable that corresponds to the same underlying variable as the current instance. This method achieves this by calling the get_degree factory method, passing the internal variable reference to generate the copy. The operation is side-effect-free with respect to the original object, meaning the state of the current instance remains unchanged.
- Returns:
A new instance of the class representing the same underlying variable.
- Return type:
Self
- create_inequality_with_degree_rhs(
- expr: fuzzy_dl_owl2.fuzzydl.milp.expression.Expression,
- inequality_type: fuzzy_dl_owl2.fuzzydl.util.constants.InequalityType,
Creates an inequality constraint where the degree variable serves as the right-hand side operand relative to the provided expression. The method constructs a new Inequation instance by subtracting the degree variable from the input expression using a coefficient of -1.0. This results in a constraint that effectively compares the expression to the degree variable according to the specified inequality_type (e.g., less than or equal to). The operation does not modify the input expression or the variable itself.
- Parameters:
expr (Expression) – The expression representing the left-hand side of the inequality.
inequality_type (InequalityType) – The relational operator (e.g., less than, greater than) defining the inequality.
- Returns:
Returns an Inequation representing the inequality expr [inequality_type] self.variable.
- Return type:
- static get_degree(value: fuzzy_dl_owl2.fuzzydl.milp.variable.Variable) Self[source]
Constructs a DegreeVariable instance using the provided Variable object as its underlying value. This static method serves as a factory function to explicitly wrap or cast a generic variable into a degree-specific representation. It does not modify the input variable but rather creates a new instance, delegating the actual initialization logic to the DegreeVariable constructor.
- Parameters:
value (Variable) – The variable to be converted into a DegreeVariable.
- Returns:
A DegreeVariable instance initialized with the provided variable.
- Return type:
Self
- get_variable() fuzzy_dl_owl2.fuzzydl.milp.variable.Variable[source]
Retrieves the underlying Variable instance stored within the DegreeVariable object. This method serves as a getter for the internal variable attribute, providing access to the symbolic variable associated with the specific degree. It is a read-only operation that does not alter the state of the instance.
- Returns:
The Variable instance associated with this object.
- Return type:
- is_number_not_one() bool[source]
Determines whether the instance represents a numeric value that is not equal to one. For the DegreeVariable class, this method unconditionally returns False, indicating that the entity does not satisfy the condition of being a number distinct from one. This behavior suggests that within the module’s type hierarchy, a DegreeVariable is either treated as a non-numeric entity or is implicitly associated with the value one.
- Returns:
Always returns False.
- Return type:
bool
- is_number_zero() bool[source]
Checks if the instance represents the numerical value zero. This method always returns False, reflecting that a DegreeVariable is a symbolic entity and not a constant. It is primarily used to distinguish variables from numeric constants during expression evaluation or simplification.
- Returns:
True if the number is zero, False otherwise.
- Return type:
bool
- is_numeric() bool[source]
Indicates that this variable does not represent a numeric constant. Unlike concrete numbers or evaluated expressions, a DegreeVariable is a symbolic entity, so this method always returns False to signal that it cannot be treated as a raw numeric value during computations or type checking.
- Returns:
True if the object is numeric, False otherwise.
- Return type:
bool
- multiply_constant(constant: float) fuzzy_dl_owl2.fuzzydl.milp.expression.Expression[source]
Multiplies the variable represented by this instance by a specified scalar constant to generate a new linear expression. The method constructs a Term object using the provided constant as the coefficient and the current variable, then wraps this term within an Expression object. This operation does not modify the original DegreeVariable instance; instead, it returns a distinct Expression representing the product of the constant and the variable.
- Parameters:
constant (float) – The numeric coefficient for the variable in the resulting term.
- Returns:
A new Expression representing the product of the provided constant and the variable.
- Return type:
- subtract_from_expression( ) fuzzy_dl_owl2.fuzzydl.milp.expression.Expression[source]
Subtracts the variable represented by this DegreeVariable instance from a given expression. It performs this operation by adding a term with a coefficient of -1.0 and the instance’s variable to the input expression. The method returns a new Expression object containing the result, ensuring that the original input expression remains unmodified.
- Parameters:
expr (Expression) – The expression from which the current term is subtracted.
- Returns:
A new Expression representing the result of subtracting the variable from the provided expression.
- Return type:
