fuzzy_dl_owl2.fuzzydl.graph.digraph

Lightweight directed graph backed by a plain adjacency list.

Drop-in replacement for the subset of networkx.DiGraph used by KnowledgeBase.is_tbox_acyclic and related helpers. Building edges via add_edge and checking for cycles via has_cycle is 10-50x faster than networkx because it avoids per-edge dict/set bookkeeping, decorator overhead, and the generic find_cycle edge-DFS iterator.

A high-performance directed graph structure designed specifically for efficient cycle detection and edge construction.

Description

The implementation serves as a highly optimized drop-in replacement for the subset of networkx.DiGraph functionality required by knowledge base acyclicity checks. By utilizing a plain adjacency list backed by a dictionary of lists, the structure avoids the significant overhead associated with generic graph libraries, such as per-edge bookkeeping and decorator calls. This design choice results in a ten to fifty-fold performance improvement when building edges and detecting cycles compared to standard networkx operations. Cycle detection is performed using an iterative three-color depth-first search algorithm, which efficiently identifies back edges without recursion. Memory usage is further minimized through the use of __slots__, and the graph allows for parallel edges while only tracking nodes that serve as edge sources.

Classes

DiGraph

Minimal directed graph using dict[int, list[int]].

Module Contents

UML Class Diagram for DiGraph

class DiGraph

Minimal directed graph using dict[int, list[int]].

add_edge(u: int, v: int) → None

Appends a directed edge u -> v to the graph. If u already has outgoing edges, v is appended to the existing list; otherwise a new list is created.

Parameters:

• u (int) – The source node.

• v (int) – The target node.

has_cycle() → bool

Detects whether the graph contains at least one directed cycle using an iterative three-colour depth-first search (white = unvisited, grey = on recursion stack, black = fully processed).

Returns:

True if a directed cycle exists, False otherwise.

Return type:

bool

number_of_edges() → int

Returns the total number of directed edges in the graph, computed by summing the lengths of every adjacency list. Because edges are appended without de-duplication, parallel edges between the same pair of nodes are counted individually.

Returns:

The total number of directed edges in the graph.

Return type:

int

number_of_nodes() → int

Returns the number of source nodes recorded in the adjacency list. Only nodes that appear as the source u of at least one add_edge call are counted; nodes seen exclusively as edge targets are not tracked as keys and therefore not included.

Returns:

The number of source nodes in the graph.

Return type:

int

BLACK: int = 2

GRAY: int = 1

WHITE: int = 0

__slots__ = ('_adj',)

_adj: dict[int, list[int] | None]

property adj: dict[int, list[int] | None]

Returns the adjacency list mapping each source node to its list of out-neighbours. Nodes with no outgoing edges may be absent from the dict.

Returns:

The adjacency mapping.

Return type:

dict[int, Optional[list[int]]]
