fuzzy_dl_owl2.fuzzydl.modifier.triangular_modifier
Implements a fuzzy logic modifier that applies a triangular membership function to concepts using three distinct boundary parameters to define degrees of membership.
Description
The implementation defines a mathematical model where membership degrees increase linearly from a lower bound to a peak and then decrease linearly to an upper bound, effectively modeling vague or imprecise linguistic terms within a fuzzy description logic system. Upon initialization, the logic enforces strict ordering constraints on the boundary parameters to ensure the formation of a valid triangle, raising an error if the configuration is geometrically impossible. By wrapping base concepts into a specialized modified structure, the software allows for the dynamic evaluation of membership values based on the specific triangular shape defined by the instance. Furthermore, the design supports logical composition through operator overloading, enabling the combination or negation of modifiers to construct more complex fuzzy expressions while maintaining immutability and hashability for use in collections.
Classes
This class implements a fuzzy logic modifier that applies a triangular membership function to concepts, defining how strongly a specific value belongs to a modified concept. The function is characterized by three parameters: the left boundary a, the peak b, and the right boundary c, which must satisfy the ordering $a le b le c$. Membership degrees increase linearly from 0 at a to 1 at b, and then decrease linearly back to 0 at c. To utilize this modifier, instantiate it with a name and the three boundary values, and then apply it to a Concept instance via the modify method, which produces a TriangularlyModifiedConcept. The class also provides a get_membership_degree method for calculating the specific membership value of a given input. |
Module Contents
UML Class Diagram for TriangularModifier
- class TriangularModifier(name: str, a: float, b: float, c: float)[source]
Bases:
fuzzy_dl_owl2.fuzzydl.modifier.modifier.Modifier
- __and__(value: Self) Self[source]
Implements the bitwise AND operation (&) for the TriangularModifier class, enabling logical conjunction between the current instance and another of the same type. This method delegates the underlying logic to OperatorConcept.and_ and returns a new TriangularModifier instance representing the combined result, ensuring that the operation does not modify the original operands in place.
- Parameters:
value (Self) – The right-hand operand for the AND operation, which must be an instance of the same class.
- Returns:
The result of the AND operation between the current instance and the provided value.
- Return type:
Self
- __hash__() int[source]
Return a hash value for this object, computed from its string representation. This approach ensures that the hash value reflects the structural identity of the object without relying on cached values or additional methods. The hash is derived from the output of the __str__ method, which provides a consistent and unique representation of the concept’s structure. This implementation does not utilize any internal caching mechanism and directly computes the hash each time it is called.
- Returns:
An integer hash value representing the structural identity of this object.
- Return type:
int
- __neg__() fuzzy_dl_owl2.fuzzydl.concept.concept.Concept[source]
Implements the unary negation operator, enabling the use of the minus sign to invert the logic of the triangular modifier. This method returns a new Concept instance representing the logical complement of the current modifier by delegating to OperatorConcept.not_. The operation is non-destructive, leaving the original modifier unchanged while generating a distinct conceptual entity that encapsulates the negation.
- Returns:
A Concept representing the logical negation of the current instance.
- Return type:
- __or__(value: Self) Self[source]
Implements the bitwise OR operation using the pipe operator (|) to combine the current instance with another TriangularModifier. This method delegates the logic to OperatorConcept.or_, which calculates the union of the two modifiers based on the underlying concept definitions. It returns a new instance of TriangularModifier representing the combined result, ensuring that the original operands remain unmodified.
- Parameters:
value (Self) – The right-hand operand to combine with the current instance using the OR operation.
- Returns:
The result of the OR operation between this instance and the provided value.
- Return type:
Self
- clone() Self[source]
Creates and returns a new instance of the class that is a copy of the current object. This method instantiates a new object using the current values of the name, a, b, and c attributes, ensuring that the returned modifier has the same configuration as the original. The operation has no side effects on the existing instance.
- Returns:
A new instance of the class with identical attributes to the current instance.
- Return type:
Self
- compute_name() str[source]
Generates a standardized string representation for the triangular modifier instance based on its defining parameters. The returned value follows the format ‘triangular-modifier(a, b, c)’, incorporating the current values of the instance’s attributes a, b, and c. This method does not modify the object’s state and is primarily useful for logging, debugging, or identifying specific modifier configurations.
- Returns:
A string representing the name of the triangular modifier, formatted with the values of a, b, and c.
- Return type:
str
- get_membership_degree(x: float) float[source]
Calculates the degree of membership for a given input value x within a triangular fuzzy set defined by the parameters a, b, and c. The function returns 0.0 if the input lies outside the interval [a, c]. For values between a and the peak b, the membership increases linearly, while values between b and c result in a linear decrease. This method performs a pure calculation without modifying internal state or causing side effects.
- Parameters:
x (float) – The input value for which to calculate the membership degree.
- Returns:
The degree of membership of the input value x to the fuzzy set, ranging from 0.0 (no membership) to 1.0 (full membership).
- Return type:
float
- modify(concept: fuzzy_dl_owl2.fuzzydl.concept.concept.Concept) fuzzy_dl_owl2.fuzzydl.concept.concept.Concept[source]
Applies the triangular modification logic encapsulated by this instance to the provided concept. This method does not mutate the original concept directly; instead, it creates and returns a new TriangularlyModifiedConcept wrapper that combines the original concept with the current modifier. This allows the modified concept to be evaluated or processed with the specific triangular characteristics defined by the modifier.
- _a
- _b
- _c
- property a: float
Returns the left endpoint of this triangular modifier’s membership function, i.e. the lower bound where the membership degree begins rising from zero toward the peak. The value is read from the private
_aattribute without modifying the instance.- Returns:
The left endpoint
aof the triangle.- Return type:
float
- property b: float
Returns the peak of this triangular modifier’s membership function, i.e. the point where the membership degree reaches its maximum value of
1. The value is read from the private_battribute without modifying the instance.- Returns:
The peak
bof the triangle.- Return type:
float
- property c: float
Returns the right endpoint of this triangular modifier’s membership function, i.e. the upper bound where the membership degree falls back to zero. The value is read from the private
_cattribute without modifying the instance.- Returns:
The right endpoint
cof the triangle.- Return type:
float
